FNC 40B系列编码器

Yeni
  • FNC 40B系列编码器
  • FNC 40B系列编码器

一般特征

  • Industry 30 mm special size, servo flange, and clamp flange
  • Robust mechanical and electrical construction
  • Protection up to IP57
  • Up to 2500 PPR max.
  • <300 kHz frequency

ISBN : FNC 40B 6630V1024 - R2


法兰直径 40 mm,
电源电压 5V : 5V in/out, 30V : 5-30V in/out, 10 - 30VDC,
连接类型 1 mt Cable, 2 mt Cable, 5 mt Cable, 7 mt Cable, 10 mt Cable, M12/4pin, M12/5pin, M16/7pin, M16/14pin, M23/12pin, 9pin/Dsup,
轴直径 4 mm, 5 mm, 6 mm, 8 mm,
脉冲 10, 16, 25, 30, 40, 50, 60, 88, 90, 100, 141, 200, 250, 300, 360, 400, 500, 512, 600, 625, 800, 900, 1000, 1024, 2048, 4096,
输出电路 / 推拉 A:1, AB:2, ABZ:3, AB+A'B:4, ABZ + A'B'Z':6,
产品组 Incremental Rotary Encoders,
