FNC 63D Series Incremental Encoder

Features

  • Industry 50 mm Standart Size, Clamping Flange, incremental encoder
  • Robust Mechanical and Electrical Construction
  • Protection up to IP67
  • Up to 5000 PPR max.
  • <300 kHz frequency

ISBN : FNC 63D 10630V1024 - R2


Flange Diameter 63 mm,
Supply Voltage 5V : 5V in/out, 30V : 5-30V in/out, 10 - 30VDC,
Connection Type 1 mt Cable, 2 mt Cable, 5 mt Cable, 7 mt Cable, 10 mt Cable, M12/4pin, M12/5pin, M16/7pin, M16/14pin, M23/12pin,
Shaft Diameter 10 mm, 12 mm, 14 mm,
Resolution / Pulse 10, 16, 25, 30, 40, 50, 60, 88, 90, 100, 200, 250, 300, 360, 400, 500, 512, 600, 625, 800, 900, 1000, 1024, 1250, 2000, 2048, 2500, 3000, 3600, 4000, 4096, 5000, 65536,
Output Circuit / Push-Pull A:1, AB:2, ABZ:3, AB+A'B:4, ABZ + A'B'Z':6,
Product Group Incremental Rotary Encoders,
